Poppet opens at 65kPa.
1½” tapered male BSP thread (outlet).
1 ½” parallel female BSP thread (inlet).
-Anodised aluminium body.
-Steel ball bearings.
-Viton sealing o-ring.
-Stainless Steel fasteners.
The swivel incorporates a check valve, to retain residual pressure in the hose. (Mandatory under NSC regulations)
Remove cotter pin to remove poppet.
Remove plug to release ball bearings and separate halves.
Adjustment or Service
